Technical Parameters:

l  Model:Win-C

l  Working area: 300*300/400*400/500*500/600*600mm

l  Laser wavelength:10640nm

l  CO2 Laser power: 30W-150W

l  Spot quality:0.23mm@300*300mm

l  Repeatibility:<8 urad

l  Long-term drit over 8hrs: <0.2mrad

l  Max.markign speed: 10000mm/s

l  Max.positioning speed:15000mm/s

l  Cutting Depth: Depends on materials

l  Cooling Method: Industrial Circulation Water Chiller

l  Aiming and Positioning: redlight preview

l  Working Voltage: 220V/380V 50/60Hz

l  Machine Dimensions/Net Weight: 180*75*165cm.

Features and Advantages:

l  The working area is fully enclosed, making operation safer

l  Paired with an industrial computer, the performance is more stable

l  The laser optical path adopts a linear design, resulting in smaller light loss.

l  Optional software functions available: 3D surface laser marking, engraving, CCD.

l  Most non-metal material application can be applicated through this super machine, laser marking, laser cutting, laser engraving.

l  Simple Field Drawing can be Performed. Supporting Files: DXF, PLT, AI, LXD, etc.

Application and Delivery:

l  1 Year Warranty for the Whole Machine

l  Factory Direct Sale, Offer Customer and Technical Support.
